DZ 1534 11/05/09
DZ 1534
Chevy Express Van Cab Length Running Boards (2009-current)
Ratchet / Wrench
3/16”
7/16”
3/8”
A B C D
E F G H
K2015P X2 X2 B 1780P
Van Board Bracket
X8 B 1791P
Strap Bracket
3/8 threaded plate
PN 407 X6
3/8 bolt
PN 114 X6
3/8 washer
PN 113 X6
¼ sheet metal screw
PN 97 X4
I J K L ¼ bolt ¼ nut
¼ washer
End Caps
PN 96B X16 PN 71B X16
PN 72B X32
EC RSP X4
Tools Required
3/16” bit
Running Boards Mounting Bracket
Angle Bracket
B 1792P X4
