Dee Zee DZ16365 - Manual (Page 7)

PASSENGER FRONT DRIVER FRONT
BRACE BRACE
*** TUBES SOLD SEPARATELY
VARIOUS X2 B 1903RP X1 B 1903LP X1
PASSENGER MIDDLE DRIVER MIDDLE PASSENGER REAR DRIVER REAR
BRACE BRACE
D F
BRACE
G E
6" OVAL SIDE STEP INSTALLATION
TOYOTA TUNDRA 2009-CURRENT
SIDE STEP TUBE
A B C
BRACE
HOLE HOLE
NOTE: THE MIDDLE BRACE NOTE: THE MIDDLE BRACE
HAS A HOLE TO IDENTIFY IT. HAS A HOLE TO IDENTIFY IT.
B 1904RP X1 B 1904LP X1 B 1905RP X1 B 1905LP X1
FROM TUBE X8 FROM TUBE X8
PN 525 X12 BOLT PACK X12 BOLT PACK X12
8mm X 25mm
FLANGE HEAD BOLT
8mm U-NUT 8mm X 20mm
FLANGE HEAD BOLT
H I J
1 of 5 4/6/2013
