Dee Zee DZ371527 - Manual (Page 4)

4" OVAL SIDEBARS WITH BENT ENDS
1999-2012 SILVERADO/SIERRA EXTRA CAB
Page 3 of 4 4/11/12 Rev2 (DP)
4. With assistance, position the Sidebar up to the (3) loose Mounting Brackets. Attach the
Sidebar to the front and rear Mounting Brackets with the included (2) 1/2” x 2” Hex Bolts, (2)
1/2” Flat Washers and (2) 1/2” Lock Washers, (Figures 2 & 4). Do not tighten hardware at this
time.
5. Attach the center Mounting Bracket to the Sidebar with the included (1) 10-1.50mm x 25mm
Hex Bolt, (1) 10mm Flat Washer and (1) 10mm Lock Washer, (Figure 3). Do not tighten
hardware at this time.
6. Level and adjust the Sidebar, tighten all hardware. Check all mounting locations for clearance
between factory steel body mount brackets and Mounting Brackets. Once satisfied with fit,
tighten all hardware.
7. Repeat Steps 1 - 6 for passenger Sidebar installation.
8. Do periodic inspections to the installation to make sure that all hardware is secure and tight.
To protect your investment, wax this product after installing. Regular waxing is recommended to
add a protective layer over the finish. Do not use any type of polish or wax that may contain abrasives
that could damage the finish.
For stainless steel: Aluminum polish may be used to polish small scratches and scuffs on the finish.
Mild soap may be used also to clean the Sidebar.
For gloss black finishes: Mild soap may be used to clean the Sidebar.
Driver side installation pictured
(Fig 1) Front Mounting Location
Factory hex bolt
Front
Fig 2
Factory welded steel body mount bracket
1/2” x 2” Hex Bolt
1/2” Lock Washer
1/2” Flat Washer
Front
