3” SIDEBAR WITH BENT END
94-01 DODGE RAM 1500 REGULAR CAB
94-02 RAM 2500-3500 REGULAR CAB (OLD BODY STYLE)
Page 2 of 2 7/5/12 Rev 1(DP)
8. Attach the Support Bracket to the body mount using the included (1) 10mm x 25mm Hex Bolt,
(2) 10mm Flat Washers, (1) 10mm Lock Washer and (1) 10mm Hex Nut. Tighten all hardware
at this time.
9. Repeat Steps 2 - 8 for passenger Sidebar installation.
10. Do periodic inspections to the installation to make sure that all hardware is secure and tight.
To protect your investment, wax this product after installing. Regular waxing is recommended to
add a protective layer over the finish. Do not use any type of polish or wax that may contain abrasives
that could damage the finish.
For stainless steel: Aluminum polish may be used to polish small scratches and scuffs on the finish.
Mild soap may be used also to clean the Sidebar.
For gloss black finishes: Mild soap may be used to clean the Sidebar.
(2) 10mm x 25mm Hex Bolts
(2) 10mm Flat Washers
1/2" x 2" Hex Bolts
1/2" Lock Washers
1/2" Flat Washers
12mm x 110mm Hex Bolt
1/2" Lock Washer
12mm Flat Washer
12mm x 110mm Hex Bolt
1/2" Lock Washer
12mm Flat Washer
1/2" x 2" Hex Bolts
1/2" Lock Washers
1/2" Flat Washers
Factory body mount
bushing and washer
Factory body mount
bushing and washer
(2) 10mm Flat Washers
(2) 10mm Lock Washers
(2) 10mm Hex Nuts
Front
(Fig 1) Driver/left side installation illustrated
Drill 7/16" hole in side of body
mount for Support Bracket
