Dee Zee DZ370781 - Manual (Page 4)

SIDEBAR
00-11 CHEVY TAHOE / 00-11 GMC YUKON
01-11 CADILLAC ESCALADE
Page 2 of 4
PARTS LIST:
1 Driver/Left Sidebar 4 ½” x 2” Hex Head Bolts
1 Passenger/Right Sidebar 4 ½” Lock Washers
1 Driver/Left Front Mounting Bracket 4 ½” ID x 1-1/2” OD x1/8” Flat Washers
1 Passenger/Right Front Mounting Bracket 2 10mm x 25mm Bolt Plates
1 Driver/Left Rear Mounting Bracket 2 10-1.50mm x 30mm Hex Head Bolts
1 Passenger/Right Rear Mounting Bracket 4 10mm Lock Washers
1 Driver/Left Front Support Bracket 4 10mm Hex Nuts
1 Passenger/Right Front Support Bracket 4 10mm ID x 30mm OD x2.5mm Flat Washers
4 12-1.75mm x 120mm Hex Head Bolts
4 12mm Lock Washers
4 12mm ID x 32mm OD x 3mm Flat Washers
Driver
Side Front
Mounting Bracket Passenger
Side Front
Mounting Bracket
Rear Mounting Brackets
Driver
Side Front
Support Bracket
Passenger
Side Front
Support Bracket
Bolt Plates
