Page 1 of 5 6/20/08 (AM) Rev A
PARTS LIST:
1 Driver/Left Sidebar 2 12-1.75mm x 25mm Bolt Plates (65mm x 20mm plate)
1 Passenger/Right Sidebar 2 12mm Lock Washers
1 Driver/Left Front Mounting Bracket 2 12mm ID x 29mm OD x 3mm Flat Washers
1 Driver/Left Rear Mounting Bracket 2 12mm Hex Nuts
1 Passenger/Right Front Mounting Bracket 10 10-1.50mm x 25mm Bolt Plates (90mm x 13mm plate)
1 Passenger/Right Rear Mounting Bracket 10 10mm Lock Washers
4 Locking Brackets 10 10mm ID x 26mm OD x 3mm Flat Washers
10 10mm Hex Nuts
8 8-1.25mm x 25mm Hex Head Bolts
8 8mm Lock Washers
8 8mm ID x 22mm OD x 1.5mm Flat Washers
INSTALLATION INSTRUCTIONS
SIDEBAR
09-ON NISSAN MURANO
PART # DZ 370503
Passenger Sidebar
Driver Sidebar
Passenger Side
Front Bracket
Driver Side
Front Bracket
Driver Side
Rear Bracket
Passenger Side
Rear Bracket
12mmx 30mm
Bolt Plate
(2 pcs)
10mmx 25mm
Bolt Plate
(10 pcs)
Front
Front Bolt Plate Locking Bracket
(4 pcs)
