Step One: Locate hardware and check contents with the hardware listed below.
QTY
DESCRIPTION
4 12mm x 120mm x 1.75mm hex bolts,
4 12mm flat washers, zinc plated
4 12mm split lock washers, zinc plated
4 12mm x 50mm hex bolt, zinc plated
4 12mm flat washers, zinc plated
4 12mm split lock washers, zinc plated
1 front support bracket, left side
1 front support bracket, right side
1 rear support bracket, left side
1 rear support bracket, right side
Step Two: Locate the left side bar, one front support bracket, left side, one front support bracket, right side
, two plastic rings, two 12mm hex bolts, 12mm flat washers and two 12mm split lock washers. Secure the brackets
and rings to the side bar as shown in fig #1. When installing side bar on pickup truck you must use the two lower
mounting holes on bracket rear support bracket. Do not fully tighten hardware at his time.
Step Three: Locate two 12mm hex bolts, two 12mm flat washers and two 12mm split lock washers. Remove the
front and rear cab mount bolts located under the cab. Place the side bar under the vehicle and position each support
bracket under the cab mounts. Secure the support brackets to the bottom of the cab mounts as shown in fig #2 & 3.
Fully tighten all hardware at this time. Torque the 12mm x 120mm bolt to 50 ft. lbs, and the 12mm x 50mm to 30
ft lbs.
Fig #1 Fig #2 Fig #3
Photos are for reference only, actual brackets may be a little different.
Step Four: Repeat steps one through three on opposite side of vehicle.
Be sure to use all hardware supplied and tighten all bolts.
Page 3 of 2
