Dee Zee DZ371263 - Manual (Page 3)

(Passenger Side Front Mounting Bracket Installation Shown)
Page 2 of 3 5/30/07 (AM)
Factory
Bolt
10mm x 25mm
Hex Head Bolts,
10mm Flat
Washers, &
10mm Nylock Nut
Insert (1) 12mm x 90mm
Hex Head Bolt w/
(1) 12mm Flat Washer
through inner side of
frame
(12mm x 90mm Hex Head Bolt)
12mm Flat Washer &
12mm Nylock Nut
(Sidebar)
½” x 2” Hex Head Bolt,
½” Lock Washer, &
½” Flat Washer
Figure 1 Figure 2
Figure 3
Figure 4 Figure 5
