Dee Zee DZ371193 User Manual
Page 2
Page 2 of 2
3/4/09 Rev 1(DP)
Driver Side Installation Pictured
Fig 1
Complete installation
Fig 2
10-1.5mm x 30mm Hex Bolts
10mm Flat Washers
10mm Lock Washers
8-1.25mm x 25mm Hex Bolts
8mm Flat Washers
8mm Lock Washers
Driver side front
installation pictured
Driver side rear
installation pictured
Rear
Front
