Dee Zee DZ370353 User Manual

Page 4

  • Text mode
  • Original mode
background image

3" SIDEBAR

07-11 CHEVY TRAVERSE/GMC ACADIA/07-10 SATURN OUTLOOK/07-09 BUICK ENCLAVE

(EXCL. 2010-11 BUICK ENCLAVE)

Page 4 of 5

3/24/11Rev1(DP)

Passenger Side Installation Pictured















































8mm x 25mm Hex Bolt
8mm Lock Washer

Fig 5

(Fig 6) Example of "Z" Bracket
installation-most of Bracket installs
inside body panel and is not visible

Fig 7

Fig 8

12mm x 45mm Bolt Plate

12mm x 45mm Bolt Plate

10mm x 35mm Bolt Plate

Front

Front

Rear

Rear

Tab with 8mm nut on
end of "Z" Bracket
