Pan/Tilt IP Camera
3.2. Video Display
This display page allows you to view the video display and control the pan/tilt
movement of the IP camera. For the first time use of this display on a computer, an
activeX component will be automatically downloaded into the browser. This could
take some time, depends on the internet speed. The component is downloaded
from a public domain, so that the computer must be connected to the Internet.
If you want to modify the video display screen size, please refer to section 3.6
for more details.
Figure 3-4: Video display page
Pan/tilt control:
1. Control by CamView – this is to enable/disable the pan/tilt control function by
CamView software.
2. Speed – this is to control the pan/tilt moving step distance for each pan or tilt
movement, fast means larger step movement.
3. Pan – click this button will let the IP CAM do one horizontal pan scan movement.
4. Tilt – click this button will let the IP CAM do one vertical tilt scan movement.
5. Patrol control – you can set up to 5 patrol points that will let the IP CAM to patrol
through these patrol points. To set the patrol point, first move the IP CAM to the
desired view position by clicking the different arrow buttons, and then press the
“position” button of the specific patrol point. The (x,y) axis values will be updated
17
