MPEG-4 wired/wireless IP Camera
4.2. Specifications
Models IP Camera
Power DC 5V, 1A
Processors RISC CPU, hardware video processing and compression.
Network interface Ethernet 10BaseT/100BaseTX, Auto-MDIX, RJ-45
Wireless interface
(for Cam(w) only)
IEEE 802.11g 6 - 54 Mbps
IEEE 802.11b 1 - 11 Mbps
Transmit power: 14.5dBm typically @ 802.11g
17.5dBm typically @ 802.11b
Receiver sensitivity: 54Mbps: Typical -73dBm @ 10% PER
11Mbps: Typical -86dBm @ 10% PER
Modes: Infrastructure and ad-hoc
Antenna gain: 1.8 dBi
Image sensor RGB VGA 1/4 inch CMOS
Automatic exposure control, automatic white balance,
automatic gain control, automatic brightness control.
Light sensitivity 0.2 Lux
Lens 3.2 mm, F2.0, viewing angle: 61°, fixed iris, focus range: 40
cm to infinity
Buttons One reset button, to factory default settings
Indicators One LED for internet connection status indication
One LED for Ethernet connection indication
Video compression MPEG-4 Part 2 (ISO/IEC 14496-2) with motion detection,
profiles: Simple Profile, level 0-3
Resolutions 160x120, 320x240, 640x480
Frame rate Up to 30 fps in all resolutions
Video streaming MPEG-4
Separate frame rate/resolution/bandwidth settings for PC
and mobile.
Image settings Resolution: VGA(640x480), QVGA(320x240),
QQVGA(160x120)
Bandwidth : 64k, 128k, 256k, 512k, 768k, 1M, 1.2M, 1.5M
bps
Frame rate : 5, 10, 15, 20, 25, 30 fps
