6
Supporting 3D Video Formats (Input):
Signal Resolution Frequency 3D video format
720p 1280 x 720
60Hz Side-by-Side (Half)
50Hz Side-by-Side (Half)
1080p 1920 x 1080
60Hz Side-by-Side (Half)
50Hz Side-by-Side (Half)
Technical Specification
HDMI Input HDMI Receiver (Type A 19-pin female) x1 / Gold plated
HDMI Output HDMI Transmitter (Type A 19-pin female) x1 / Gold plated
HDMI Standard (RX)
(TX)
Compliant with HDMI 1.3a , HDCP 1.2
Compliant with HDMI 1.3a , HDMI 1.4a 3D , HDCP 1.2
Operation pixel
frequency range
link clock rate of 225MHz
Single Link Range 2.25Gbps
HDMI DDC Signal 5Vp-p
Input Video Signal 1.2 Vp-p max.
Remote Control Frequency carrier of 38kHz
Power Supply DC 5V/1A
Support Output
3D Formats
Active Shutter 3D Display based on same conditions
1. Frame Packing - Frame sequential 60Hz ( DLP-Link)
2. Side-by-Side (Half)
3. Chequer Board Encoding ( Left-Blue / Right-Red )
TROUBLE SHOOTING
1. When there is no picture presented, please:
 Make sure the direct connection from the source device to the display device without the 3D
Creator is working.
 Check if all connectors are connected well; and check if all cables can support the transmission
speed. High Speed HDMI cables are recommended.
 Check the power of 3D Creator in on.
 3D Creator does not have de-interlace function, please set the output signal of source devices
to 1080p, 720p, or 480p.
 3D Creator may not support some 3D videos that are formatted in 1080p/24fps. It may cause no
pictures presented on the sink device.
2. When there is only picture displayed and without sound:
 Check the cable connection to see if it fits properly.
 Check your cable to see if it supports video transmission only (DVI) or it is damaged.
 HDCP may not match very well at first connection; please restart your 3D Creator.
