When the

icon appears on desktop and a small icon

appears from

taskbar, the installation is completed.

2.2 Please double click

from desktop to activate KMDS if needed.

(*The small

icon

indicates the ready status. **After AP installation is completed, the AP is in your

computer. The KMDS can be automatically activated but please connect KM Switch with your

computers before turn on computers. ***If you exit the function or unplug KM Switch, you can click

KMDS from the desktop to activate).

C. The Icon Status:

1. KM Switch function selected:

2. KVM PIP function selected:

(left-click on icon to pop-up or close)

3. Data transfer:

and pop-up window

4. The KMDS on computers is off-line:

5. The KMDS on computers is on-line:

6. The function display window:
