Smart Data Link with KM Switch
Introduction
The Smart Data Link with KM Switch lets you access multiple computers and
associated monitors by sharing a single keyboard and mouse to switch between two
computers. This product has the Data Link function allowing you to copy files on
desktop between two computers. And it is easy for you to cut texts and paste them
between computers. The PIP mode is the value added to this device.
Features
◆ Picture in Picture (PIP) function.
◆ KM function allows user to control computers and associated display monitors.
◆ File transfer between two computers.
◆ Copy and Paste text between two computers.
◆ Performs Data Transfer between two computers.
◆ Data Link function conforms high speed USB specification.
◆ No CD software driver to install is needed.
◆ Switch Mode:
1. Mouse movement.
2. Application icon.
◆ No extra power is required.
◆ Windows XP, Vista and *7
(Home and Professional edition) compatible.
Specifications
Function Specification
Item Number MD-KM-PIP
PC Port 2
Cable Length 1.5m or 2m
Operating Voltage USB power (DC 5V)
Power Consumption 85mA
Operating System Windows XP / Vista / *7
Weight 45g
Dimension (L x W x H) 40 x 15 x 10 (mm) or 45 x 20 x 10 (mm)
* The specification is subject to change without further notice.
Package Contents
 1 x Smart Data Link with KM Switch
 1 x User Manual
