Monoprice 6529 MHP-100 - Manual (Page 6)

6 of 8
Insert and tighten three
M6 x 60mm hexagon fillister head screws (M) to lock
adjuster tube (AA) to ceiling plate (EE) and lock it
by nut (M).
‡ Installer must verify that the ceiling will safely support
the combined weight of all attached equipment and
hardware.
WARNING
Slide extension pipe (CC ) over adjuster tube (BB)
to the desired height. Attach with two M6 x 55 mm
hexagon fillister head screws (N) and lock nut (N).
Slide extension pipe (BB) over adjuster tube ( AA)
to the desired height. Attach with two M6 x 55 mm
hexagon fillister head screws (N) and lock nut ( N ).
Installation of Extension Column
EE
AA
N
BB
M
CC
N
M
