Tools Needed for Assembly
stud finder ("edge to edge" stud finder is recommended)
phillips screwdriver
¢6.0 drill
drill
pencil
level
tape measure
bit and ¢10.0 masonry drill bits
WARNING
Table of Contents
Parts List ........................................................................................................................................................................ 3
Installation to Wood Stud Wall ....................................................................................................................................... 4
Installation to Solid Concrete and Cinder Block .............................................................................................................. 5
Attaching adapter plate to Screen
............................................................................................................
............................................................................................................ ...........................
...
6
ǃ7
8
Mounting the
Tilt Adjustment and Cord Covers
Be sure to read this entire manual thoroughly and you fully understand all the instructions and warning before
attempting to begin your installation.
This product should only be installed by someone
Make sure that the support surface will safely support the combined load of the mount, the display and all
attached hardware and components.
This wall bracket will only support flat panel displays(LCD,Plasma).The maximum load capacity is 300 pounds.
If mounting to a wall of wood stud construction, be sure that mounting bolts are anchored to the center of the
studs.
Always have someone assist you to lift and position your equipment.
Tighten screws and bolts firmly, but do not over tighten. Over tightening can damage the items and greatly reduce
their ability to hold. Please refer to suggested torque values where applicable in these instructions.
Note: Read entire instruction sheet before you start installation and assembly.
who has a basic knowledge of buiding construction,in stallations
and fully understands these instructions.
