www.avenview.com 9
1.10 General Troubleshooting
Problem Possible Solution
No Image

Check if connection to the source and the display are correct.

Ensure that display device supports 480p, 720p and 1080p
resolution
Screen Defects Appear

This product supports up to 1080p (1920x1200) resolution.

Check the DVI and HDMI connection

If outputting from a PC. Check the maximum resolution range
of the graphics card.
Section 2: Specifications
Item Description
Units HDM-C5-3-S HDM-C5-3-R
Unit Description HDMI 1.3 Transmitter HDMI 1.3 Receiver
HDMI Compliance HDMI 1.3c
HDCP Compliance Yes
Video Bandwidth Single Link 340 MHz (10.2Gbps)
Supported Resolutions 480i / 480p / 720p / 1080i / 1080p60
Resolution and Distance
(8-bit) Full HD: (1080p) ~40meter (130feet) (CAT5e) / 50meter (165feet) (CAT6)
HD: (720p/1080i)-50meter (165feet) (CAT5e) / 60meter (200feet) (CAT6)
Audio Support Surround Sound (up to 7.1 Ch) or Stereo Digital Audio
Equalization - 8 Level Digital Control
Input TMDS Signal 1.2 Volts (peak-to-peak)
Input DDC Signal 5 Volts (peak-to-peak, TTL)
ESD Protection
- Human body model — ±15kV (air-gap discharge) & ±8kV (contact discharge)
- Core chipset — ±8kV
Input 1 x HDMI 1 x RJ45
Output 1 x RJ45 1 x HDMI
HDMI Connector Type A (19 pin female)
RJ45 Connector WE/SS 8P8C with 2 LED indicators
Rotary Switch Mode EQ
Dimensions 3.3” X 2.4” x 1” (L x W x H)
Power Supply 5V 4A DC
Power Consumption 1 Watt (max)
Environmental
Operating Temperature
32˚ ~ 104˚F (0˚ to 40˚C)
Storage Tempearture -4˚ ~ 140˚F (-20˚ ~ 60˚C)
Relative Humidity 20~90% RH (no condensation)
