4

Settings

34

Setting Menu (Continued)

Input Signal > Aspect (Video)

14

Aspect (Video)

Confi gures the screen size of the projected image.

4:3

Sets the screen size of the projected image as 4:3.

16:9

Sets the screen size of the projected image as 16:9.

Zoom

Zooms the images. (This item cannot be selected in the case of HD signals.)

This setting can also be confi gured from the remote control. (

P16)

The

items

cannot be set in the case of PC signals.

Input Signal > Aspect (Computer)

15

Aspect (Computer)

Confi gures the screen size of the projected image.

Auto

Enlarges the PC signal horizontally/vertically until it fi ts the panel height, and displays
it in the original aspect ratio.

1:1

Displays the PC signal corresponding to the panel at one dot per pixel ratio. The PC
screen can be shown in the original size.

Full

Enlarges the PC signal horizontally/vertically.

This setting can also be confi gured from the remote control. (

P

16)

This setting cannot be set in the case of SD or HD signals.

Input Signal > V-Stretch (when HD or SD video signals are input)

16

V-Stretch

When set to On , the projected 2.35:1 image will be stretched vertically to the panel resolution.

On

The projected 2.35:1 image will be stretched vertically to the panel resolution.

Off

Projects the 2.35:1 image as-is. (Black bands will be displayed on the top and bottom.)

This setting cannot be set in the case of PC signals.

Input Signal > Picture Position

17

Picture Position

Adjusts the horizontal/vertical position of the projected image.

The position of the image varies depending on the input signals. The image of some signals may not be fully displayed. Adjust the position

of image using this menu to display the image properly.

Off

On
