2 Preparation
20
Connecting via HDMI Cable
Connecting via HDMI-DVI Conversion Cable
●
If noise is produced, take PCs (including notepads) away from this unit.
HDMI 1 HDMI 1 HDMI 2 HDMI 2 VIDEO VIDEO
S-VIDEO S-VIDEO
Y
R SYNC SYNC
C B /P B C R /P R
B G
This unit
HDMI cable (sold separately)
To HDMI 1 or HDMI 2 input terminal
HDMI output terminal
DVD recorder
HDMI 1 HDMI 1 HDMI 2 HDMI 2
VIDEO VIDEO S-VIDEO S-VIDEO RS-232C RS-232C Y
R SYNC SYNC
C B /P B C R /P R
B G
This unit
To HDMI 1 or HDMI 2 input terminal
HDMI-DVI conversion cable
(sold separately)
Notebook PC
DVI output terminal
Connecting(Continued)
