ENGLISH
21
Getting Started
Preparation
Basic Operation
Troubleshooting
Settings
Others
Connecting via SCART-RCA Cable
●
Set COMP. in the setting menu to SCART .(
P33 -
12
)
Connecting via RGB Video Cable
●
Set COMP. in the setting menu to RGB .(
P33 -
12
)
●
For information on compatible input signals, see Specifi cations . (
P56)
HDMI 1
HDMI 1
HDMI 2
HDMI 2
S-VIDEO
S-VIDEO
RS-232C
Y
R
VIDEO
VIDEO
SYNC
SYNC
C
B
/P
B
C
R
/P
R
B
G
This unit
To RGB video input terminals
RGB video cable
(sold separately)
R(Red)
B(Blue)
G(Green)
(Includes sync signals)
RGB video output terminals
Device equipped with RGB output
HDMI 1
HDMI 1
HDMI 2
HDMI 2
VIDEO
VIDEO
S-VIDEO
S-VIDEO
RS-232C
Y
R
SYNC
SYNC
C
B
/P
B
C
R
/P
R
B
G
This unit
DVD player for European market
SCART terminal
SCART-RCA cable
(sold separately)
To RGB video and
sync signal input terminals
