I. Introduction:
This instrument is a four channel digital thermometer for use with any K-type thermocouple as
temperature sensor. Temperature indication follows National Bureau of Standards and IEC584
temperature/voltage table for K-type thermocouples. It internal memory can keep up to 16,000
records per channel. (note1.) It uses RS232 interface to perform bi-directional communication with
PC.
II. Specifications:
Numerical Display: 4 digital Liquid Crystal Display per channel.
Measurement Range: -200°C ~ 1370°C -328°F ~ 2498°F
Resolution: -200°C~ 200°C 0.1°C; 200°C ~1370°C 1°C
-200°F~ 200°F 0.1°F; else 1°F
Input Protection at Thermocouple Input: 60V DC, or 24Vrms AC
Environmental:
ο Operating Temperature and Humidity: 0°C ~50°C (32°F ~ 122°F) ; 0 ~ 80% RH
ο Storage Temperature and Humidity: -10°C to 60°C (14°F ~ 140°F); 0 ~ 80% RH
ο Altitude up to 2000 meters.
Accuracy: at ( 23 ± 5°C )
Range Accuracy
-200°C ~ 200°C
±(0.2% reading + 1°C)
200°C ~ 400°C
±(0.5% reading + 1°C)
400°C~1370°C
±(0.2% reading + 1°C)
-328°F ~ -200°F
±(0.5% reading + 2°F)
-200°F ~ 200°F
±(0.2% reading + 2°F)
200°F ~ 2498°F
±(0.3% reading + 2°F)
Note:
The basic accuracy Specification does not include the error of the probe. Please refer to the
probe accuracy specification for additional details.
Electromagnetic Compatibility: Total accuracy = specified accuracy ±2°C(3.6°F)
Sample Rate: 3 seconds per period
Dimension: 184
Ч
64
Ч
30mm
Weight: 250g Approx.
Accessory: K Type Bead Probe
×
2, Battery, Carrying Case, Instruction Menu, Software program,
RS-232 Connection Cable
Power requirement: 9 Volt Battery
Battery Life: Approx. 100hrs with alkaline battery
AC Adapter: 9VDC ±15% 100mA
Plug Diameter: 3.5mm
×
1.35mm
Option : AC Adapter
note1:
Every time you press "REC" button to start recording data and press "REC" button again to stop
recording, there will be a data set in memory, you can store as many data sets as you want until memory
is full.
Temperature Coefficient:
For ambient temperatures from 0°C ~ 18°C and 28°C
~ 50°C, for each °C ambient below 18°C or above
28°C add the following tolerance into the accuracy
spec.
0.01% of reading + 0.03°C
( 0.01% of reading + 0.06°F )
