THERMOMETER
5
F 2498
1370 C
C F
T1-T2
T2 24 V MA X
60V T1 T4 T3
3
4
5
2
1
O U T P U T
D C 9V
6
7
8 C A L
9
MANUAL FOR SAFETY
OPEN
NEDA 1604 6F22 006P
PLEASE READ
9V BATTERY
POWER-UP OPTIONS
RANGE
F 328
200 C
REL
HOLD
Button Location:
○ 1 K type temperature sensor T1 to T4 input connector
○ 2 LCD display ○ 3 ON/OFF & Backlight button
○ 4 Hold button ○ 5 Relative button
○ 6 T1-T2 button ○ 7 MAX MIN function control button
○ 8 °C, °F control button ○ 9 Offset calibration screw
○ 10 Digital output connector ○ 11 AC power adapter connector
○ 12 Tripod connector ○ 13 Battery cabinet cover
