THERMOMETER
1
CONTENTS
TITLE PAGE
I. Introduction……………………………….…………..…….….. 1
II. Specifications………………………………..………………...
1
III. Symbol Definition and Button Location………………….…
3
IV. Operation Instructions………………………...……………...5
4.1 Power-Up & turn ON/OFF backlight…………...……….. 5
4.2 Connection the Thermocouples…………..……….……..5
4.3 Selecting the Temperature Scale………………………...5
4.4 Data-Hold Operation………………………….…………...5
4.5 T1-T2 Operation…………………………………………...
5
4.6 Relative Operation…………………………………………6
4.7 MAX/MIN Operation…………………………………….…
6
4.8 Auto Power Off………………………………………….… 7
4.9 Low Battery Condition …………………………………… 7
4.10 Calibration Point………………………………….……… 7
4.11 Digital Output…………………………………………….. 7
Appendix: Thermocouple probe specification……………… 8
I. Introduction:
This instrument is a four channel digital thermometer for
use with any K-type thermocouple as temperature sensor.
Temperature indication follows National Bureau of
