Safety / Introduction

Page 4

WARNING

GASOLINE, AS WELL AS OTHER FLAMMABLE MATERI-
ALS AND LIQUIDS (ADHESIVES, SOLVENTS, ETC.), AND
THE VAPORS THEY PRODUCE, ARE EXTREMELY DAN-
GEROUS. DO NOT HANDLE, USE, OR STORE GASOLINE
OR OTHER FLAMMABLE OR COMBUSTIBLE MATERIALS
IN THE VICINITY OF A HEATER.

CAUTION

VERIFY PROPER OPERATION AFTER SERVICING.

W

ATER

T

EMPERATURE

S

AFETY

Elevated water temperature can be hazardous. The U.S.

Consumer Product Safety Commission has these guidelines:

1. Spa water temperatures should never exceed 104°F

(40°C). A temperature of 100°F (38°C) is considered safe
for a healthy adult. Special caution is suggested for young
children.

2. Drinking of alcoholic beverages before or during spa or

hot tub use may cause drowsiness which could lead to
unconsciousness and subsequently result in drowning.

3. Pregnant Women Beware! Soaking in water over 102°F

(39°C) may cause fetal damage during the first three
months of pregnancy resulting in the birth of a brain-dam-
aged or deformed child. Pregnant women should stick to
the 100°F (38°C) maximum rule.

4. Before entering the spa or hot tub, users should check the

water temperature with an accurate thermometer; spa or
hot tub thermostats may err in regulating water tempera-
tures by as much as 4°F (2.2°C).

5. Persons with a medical history of heart disease, circulato-

ry problems, diabetes, or blood pressure problems should
obtain a physician's advice before using spas or hot tubs.

6. Persons taking medications which induce drowsiness,

such as tranquilizers, antihistamines, anticoagulants, or
recreational drugs should not use spas or hot tubs.

INTRODUCTION

R

ATINGS AND

C

ERTIFICATIONS

This pool/spa heater is design-certified and tested under

the latest requirements of ANSI Z21.56 / CSA 4.7 Standard
for Gas-Fired Pool Heaters. The heater can be used either
indoors or outdoors. If necessary, the top of the heater can
be changed after installation to accommodate indoors or out-
doors.

WARNING

USE OF ANY PARTS NOT MANUFACTURED AND/OR
APPROVED BY THE MANUFACTURER WILL VOID THE
WARRANTY.

A

MBIENT

T

EMPERATURE

R

ATING OF

C

OMPONENTS

Millivolt heater

+32°F to +175°F

Electronic heater only -40°F to +175°F

M

ODEL

I

DENTIFICATION

The model identification number and heater serial number

are found on the heater rating plate.

Figure 2. Location of Heater Rating Plate.

The model identification number will be similar to P-

R130A-EN-X, where:

"EP" designates an Electronic heater using Propane gas

"EN" designates an Electronic heater using Natural gas

"MP" designates a Millivolt heater using Propane gas

"MN" designates a Millivolt heater using Natural gas

"P" prefix designates plastic (Polymer) headers

"X" suffix designates Cupro-Nickel tubing

"C" suffix designates Copper tubing

S

PECIFICATIONS

Table 2. 130A Specifications.

U

NPACKING

On receipt of the heater it is suggested that visual checks

are made for external damage to the shipping carton. If the
carton is damaged, make a note to that effect on the Bill of
Lading when signing for the shipment. Remove the heater
from the shipping packaging. Report any damage to the carri-
er immediately.

On occasion, items are shipped loose. Be sure that the

correct number of packages are received, as indicated on the
Bill of Lading.

Claims for shortages and damages must be filed with the

carrier by consignee. Authorization to return goods must be
received from the factory prior to shipping. Goods returned to
the factory without an authorized Returned Goods Receipt
number will not be accepted. All returned goods are subject
to a restocking charge.

Heater Model

Input (BTUH)

130A

130,000

1/2"

1-1/2" or 2" NPT

Gas

Connection

(NPT)

Water

Connection

Shipping

Weight (lbs.)

Standard Heater
w/Stackless Top

140
