Sper Scientific 850013 Advanced Datalogging Sound Meter User Manual
Page 26
26
PC CONNECTION
side. Click any data set to graph that set. The right side of
the screen displays the waveform graph and statistical
information of the selected data set.
Recording Real Time Data in Waveform
1. Press POWER to turn the meter on.
2. Connect the meter to the PC’s RS232/USB serial port
with the USB cable.
3. Start the software program.
4. If the connection is successful, the same value will
appear on the Panel Window and the meter. If the
meter fails to connect with the PC, “No Connection”
appears on the Panel Window.
5. When successfully connected to the PC, click to start
recording real time data. A waveform appears on the
Real Time Graph Window.
6. Click to stop recording.
Saving Real Time Data to a File
1. Select the graph window to save to the PC and click on
the graph window to make it active.
