Speedtech Clutch Master Bracket - Manual (Page 2)

2 | P a g e
Clutch Master Cylinder Bracket Kit Checklist
Installation Instructions (1)
Firewall Bracket (1)
5/16 x ½” bolts (2)
Adjustable push rod conversion assembly (1)
.
Pushrod modification for GM master Cylinder #
LT applications- Master Assembly 12559912
LS applications- Master Assembly 12570277
The push rod on the GM master cylinder is too long and needs to be shortened.
Supplied with this kit is a new sleeve with heim joint and mounting bolt.
Remove the crimped on factory rod end. We suggest using a die grinder or cut
off wheel to score the rod end portion lengthwise until you are able to remove it
from the push rod shaft. Be careful not to cut into the master cylinder push rod
shaft.
