Assembled Views
ENGLISH
handle grip
power cord
bumper
upper
cord wrap
lower
cord wrap
ON/OFF switch
cord spring
height
adjustment
knob
cloth
bag spring
bag
assembly
wheels
handle
release pedal
upper
cord wrap
Owner’s Manual
operating and maintenance instr
uctions
instructions
Manual Del Propietario
instrucciones de funcionamiento y
de mantenimiento
Le Manuel du Propriétaire
instructions fonctionnantes
et de services
Customer Service:
1-800-892-6806
www.rcpworksmarter.com
FOR COMMERCIAL USE
x2
x2
Tool Needed
Supplemental
Contents
Bag Assembly
A
C
D
B
I
E
F
J
K
L
Fasteners
(actual size)
G
H
Reorder Numbers
9VCVBE12 (belt)
9VCVPB12 (paper bag)
9VCVBA12 (cloth bag)
Reorder by logging on to
www.rcpworksmarter.com
or
by contacting your local distributor. Call customer service
at 1-866-524-5233 for service and to order genuine
Rubbermaid Commercial Products replacement parts.
upper handle tube
upper cord wrap
lower handle tube
lower cord wrap
base stem
male screw
female screw
B
A
C
D
E
nozzle
F
dirt tube
paper bag
G
H
cloth bag
I
J
IJ
K
extra belt
JL
Parts List
Package Contents
Please confirm that all items shown in the image below are included in the packaging.
If any parts are missing, please call customer service at 1-866-524-5233.
