American DJ H2O - Manual

Disconnect the unit's main power supply. Remove the
thumb screw on the top of the unit. Remove the trap
door. Carefully remove the old bulb from the unit
(Be sure the unit has had ample time to cool before
attempting to replace the lamp). Carefully install the
new lamp, follow all the installation guide lines that are
included with your new lamp. Replace the trap door
and thumb screw.
Caution: Always replace with the exact same type lamp
and fuse, unless otherwise specified by an authorized
American DJ
®
technician.
Congratulations and thank you for purchasing the
American DJ
®
H2O.™ This fixture is designed to
operate as a stand alone unit. It has been tested
and lamped at the factory there is no assembly
necessary. The H2O™ was created to meet the
demands of theatrical groups and production groups.
The desire was to create a low cost unit with an
incredible effect, without any strong flashing lights
or special fog needs. When used with the internal
clear gel this unit creates the effect of rippling water
movement or use the internal orange gel to create
a dramatic fire simulation. This unit comes with 9
built in colors that can be used to create a variety of
different and unique effects.
American DJ
®
User Instructions
American DJ Supply Inc®. Los Angeles Ca. 90058 USA www.americandj.com H2O™
Caution: Please read and follow all instruction before attempting to operate this or any other electrical unit.
H2O - Introduction
H2O - Lamp Replacement
H2O - Functions and Controls
required. The unit’s two internal wheels will immediately
begin to turn when power is applied. On the rear of the
unit there is one toggle switch that is used to control
the internal color wheel. You may leave the color wheel
on and it will continuously rotate through all the colors.
To create a single color effect, let the color wheel
rotate until it reaches your desired color and then turn
the color wheel switch to the off position. You may
also create a more dramatic effect by use split color
combination by stopping the wheel anywhere between
two adjacent colors.
This unit is not sound activated, so there is no need
for an audio source.
There is no power switch, after plugging the unit in, if
there is no lamp output check the fuse and bulb. If
the fuse and bulb are good, please return the unit to
your dealer for servicing
Technical Specifications:
Model: H2O™
Lamp: JCR/H5 15V, 150W
Voltage: 110~120v
Dimensions: 13.75" x 5.75" x 13.75"
Colors 9 + White
Weight: 19 Lbs
Fuse: 2Amp GMA
Duty Cycle: 15min on/off
Simplicity at it's beast, this fixture is ready to be
plugged in right out of the box, there is no assembly
