Page 5
5
135
o
90
o
45
o
180
o
0
o
180
o
135
o
90
o
45
o
0
o
8760 Series Damper Specifications
SH-76_ _ _
BD-76_ _ _
Part
Overall
Shaft
Metering
Body
Suffix
Length
Length
Rod Length
Length
100
10.0”
5.250
2.525
3.915
105
10.5”
5.550
2.775
4.165
110
11.0”
5.750
3.025
4.415
115
11.5”
6.000
3.275
4.665
120
12.0”
6.250
3.525
4.915
125
12.5”
6.500
3.775
5.165
130
13.0”
6.750
4.025
5.415
135
13.5”
7.000
4.275
5.665
140
14.0”
7.250
4.525
5.915
145
14.5”
7.500
4.775
6.165
150
15.0”
7.750
5.025
6.415
155
15.5”
8.000
5.275
6.665
160
16.0”
8.250
5.525
6.915
175
17.5”
9.000
6.275
7.665
180
18.0”
9.250
6.525
7.915
200
20.0”
10.250
7.525
8.915
220
22.0”
11.250
8.525
9.915
240
24.0”
12.250
9.525
10.915
8760 Series Part Lengths
DIM “A”
DIM “B” DIM “C”
10.0
1.875
5.850
10.5
2.125
6.100
11.0
2.375
6.350
11.5
2.625
6.600
12.0
2.875
6.850
12.5
3.125
7.100
13.0
3.375
7.350
13.5*
3.625
7.600
14.0
3.875
7.850
14.5
4.125
8.100
15.0
4.375
8.350
15.5
4.625
8.600
16.0
4.875
8.850
17.5
5.625
9.600
18.0
5.875
9.850
20.0
6.875
10.850
22.0
7.875
11.850
24.0
8.875
12.850
DIM “D”
4.00
5.00
6.00
DIM “E”
2.277 for 2.100 Eyelet (std.)
2.477 for 2.300 Eyelet
2.777 for 2.600 Eyelet
* 13.5 (DIM “A”) max for 45mm
DIM “A”
Eye to Eye
DIM “B”
Stroke
DIM “C”
Body Length
Dim “E”
DIM “D”
Reservoir Length
45mm (1.87 OD) = 2.00” ID
Spring Hardware
55mm (2.06 OD) = 2.25” or 2.50” ID
Spring Hardware
