Flow Rate Through Multiple Bleed Holes
Hole
1
2
3
4
5
6
7
8
9
Diameter
Hole
Holes
Holes
Holes
Holes
Holes
Holes
Holes
Holes
0.010
0.10
0.20
0.30
0.40
0.50
0.60
0.70
0.80
0.90
0.012
0.14
0.29
0.43
0.58
0.72
0.86
1.01
1.15
1.30
0.015
0.23
0.45
0.68
0.90
1.13
1.35
1.58
1.80
2.03
0.018
0.32
0.65
0.97
1.30
1.62
1.94
2.27
2.59
2.92
0.020
0.40
0.80
1.20
1.60
2.00
2.40
2.80
3.20
3.60
0.022
0.48
0.97
1.45
1.94
2.42
2.90
3.39
3.87
4.36
0.024
0.58
1.15
1.73
2.30
2.88
3.46
4.03
4.61
5.18
0.025
0.63
1.25
1.88
2.50
3.13
3.75
4.38
5.00
5.63
0.026
0.68
1.35
2.03
2.70
3.38
4.06
4.73
5.41
6.08
0.028
0.78
1.57
2.35
3.14
3.92
4.70
5.49
6.27
7.06
0.030
0.90
1.80
2.70
3.60
4.50
5.40
6.30
7.20
8.10
0.032
1.02
2.05
3.07
4.10
5.12
6.14
7.17
8.19
9.22
0.034
1.16
2.31
3.47
4.62
5.78
6.94
8.09
9.25
10.40
0.035
1.23
2.45
3.68
4.90
6.13
7.35
8.58
9.80
11.03
0.036
1.30
2.59
3.89
5.18
6.48
7.78
9.07
10.37
11.66
0.038
1.44
2.89
4.33
5.78
7.22
8.66
10.11
11.55
13.00
0.040
1.60
3.20
4.80
6.40
8.00
9.60
11.20
12.80
14.40
0.045
2.03
4.05
6.08
8.10
10.13
12.15
14.18
16.20
18.23
0.050
2.50
5.00
7.50
10.00
12.50
15.00
17.50
20.00
22.50
0.055
3.03
6.05
9.08
12.10
15.13
18.15
21.18
24.20
27.23
0.060
3.60
7.20
10.80
14.40
18.00
21.60
25.20
28.80
32.40
0.062
3.84
7.69
11.53
15.38
19.22
23.06
26.91
30.75
34.60
0.064
4.10
8.19
12.29
16.38
20.48
24.58
28.67
32.77
36.86
0.066
4.36
8.71
13.07
17.42
21.78
26.14
30.49
34.85
39.20
0.068
4.62
9.25
13.87
18.50
23.12
27.74
32.37
36.99
41.62
0.070
4.90
9.80
14.70
19.60
24.50
29.40
34.30
39.20
44.10
0.072
5.18
10.37
15.55
20.74
25.92
31.10
36.29
41.47
46.66
