Chapter 1 11
Bottom Panel
Indicators
The computer has four easy-to-read status indicators on the upper-right above the keyboard, and four on the
front panel.
External display
(VGA) port Connects to a display device(e.g.,
external monitor, LCD projector).
Battery Powers the computer
# Item Description
1 Battery lock Locks the battery in position.
2 Cooling fan Helps keep the computer cool.
Note: Do not cover or obstruct the opening
of the fan.
3 Hard disk bay Houses the computer’s hard disk (secured
with screws)
4 Memory compartment Houses the computer’s main memory.
5 Battery release latch Release the battery for removal.
6 Battery bay Houses the computer’s battery pack.
# Icon Item Description
