MBRP S5400 - Manual (Page 2)

S5400 © 12/07 PAGE 2 OF 4
2004-2006 Nissan Titan
These instructions cover the system: S5400304
Removal of stock system:
1. Apply a penetrating lubricant liberally to all exhaust fasteners,
hangers and rubber insulators.
2. Mark 8” from the outside of the vehicle stock hanger just after
the Y pipe. Refer to Figure 1.
3. Cut the pipe at the mark. Remove any burrs on the cut pipe.
Refer to Figure 2.
4. Lubricate then remove hardware from the rearmost exhaust
hanger. Keep for reinstallation. Refer to Figure 3.
5. Remove hardware from flange behind muffler. Remove the
hangers from the rubber insulators. Remove the exhaust from the
vehicle. Refer to Figure 4.
Figure 1
Figure 2
Figure 3
Figure 4
