ADC Gas Electric Steam WDA-540 - Manual (Page 50)

48
Q. PROGRAM LOCATION 14 (PL14)
Maximum Time for Auto Dry
Location to be viewed/changed.
Press “Perm Press” key.
Display will read “Adrt,” automatic
maximum drying time for 3-seconds
and then time programmed. If no
change, press “Perm Press” key,
otherwise press “HI” or “LO”
keys and then “Perm Press” key.
Summary: The maximum auto dryness time is programmable from 1 to 99 minutes.
PL14
Adrt
Perm Press
25 HI Temp
Perm Press
LO Temp
Refer to Section V for instructions
on entering program locations.
(Wait 3-Seconds)
("Hold In" to Accelerate) ("Hold In" to Accelerate)
PL15
Proceed to next location
to be changed
To exit program mode,
open program switch
Time Decrease Time Increase
