S6150 © 11/12 PAGE 4 OF 4
6. Install the Hanger Assembly using the hardware provided.
Refer to Figure 9.
6. Install the Tail Pipe to the Over Axle Pipe using the remaining 4”
Clamp. Refer to Figure 10.
7. Install and adjust the Exhaust Tip to suit. Tighten the bolt located on the
Exhaust Tip.
8. Adjust the Tail Pipe and check along the whole length of the exhaust
system to ensure there is adequate clearance around the fuel and brake lines
or any wiring. If any interference is detected relocate or adjust. Start at the
front of the exhaust system and begin tightening all connections.
Congratulations! You are ready to begin experiencing the improved power,
sound and driving excitement of your MBRP Inc. performance exhaust
system. We know you will enjoy your purchase.
Figure 9
Figure 10
