9.
Install the Passenger Side Tailpipe from the rear of the truck,
over the axle and attach to the lower outlet of the Muffler. Install
the tailpipe hanger into the OEM hanger and adjust for maximum
axle clearance to complete. See Figure 10.
10.
Install remaining Clamps around pipes as shown in the opening
diagram. Adjust Tailpipes and check along the whole length of
the exhaust system to ensure that there is adequate clearance
around the spare tire, fuel and break lines or any wiring. If any
interference is detected relocate or adjust.
11.
Make sure the exhaust is in the place before tightening clamps. Start at the front of the exhaust system
and begin tightening all connections.
12.
Install and adjust Tips to suit. Using a 17mm wrench tighten lock bolt located on each Tip.
Congratulations! You are ready to begin experiencing the improved power, sound and driving excitement of
your MBRP Inc. performance exhaust system. We know you will enjoy your purchase.
Figure 10
