Manley STEREO VARIABLE MU LIMITER / COMPRESSOR - 3/2004 User Manual
Page 2
CONTENTS
SECTION
PAGE
INTRODUCTION 3
MAINS CONNECTIONS
4
INSTALLATION 5
FRONT PANEL
6
REAR PANEL
7
EXAMPLE SETTINGS
8
FRONT PANEL ADJUSTMENTS
9
OPERATIONAL NOTES
10
MASTERING AND M/S MODELS
11
T-BAR MODIFICATION
12
GAIN REDUCTION CURVES
13
SPECIFICATIONS 14
TECHNICAL NOTES
15
SERVICE ADJUSTMENTS
16
BLANK TEMPLATE TO STORE SETTINGS
17
rev3.12
