SPECIFICATIONS

- MANLEY input & output transformers with nickel laminations in mu-metal cases with flat fre-

quency response from 20Hz-25kHz

- BALANCED INPUTS & OUTPUTS (600 Ohms)

- Fully differential ALL-TUBE circuitry using one each 5670, 5751, 7044 or 5687, & 12AL5 per

channel (T-BAR mod replaced 5670’s with 2 pairs of 6BA6’s)

- Independently regulated B+ and Heater supplies

- Hard-wire BYPASS switch

- INPUT LEVEL switch: -8, -4, -2, -1, 0, +1, +2, +4, +8dB

- RECOVERY 5 steps: 0.2s, 0.4s, 0.6s, 4sec., 8sec.

- Variable ATTACK: 25msec-70msec

- Continuously variable THRESHOLD

- LIMIT (4:1 to 20:1) or COMPRESS (1.5 to 1)

- HP Side Chain Filter: 6dB per octave, approximately -3dB at 100Hz.

- Large ILLUMINATED Sifam METERS (older units before serial number MSLC61642 shipped

before 12/2003 use: 26V 1.2W FESTOON LAMPS; Manley’s Part Number: VAR016B) Order

spare bulbs using our parts order form. (newest units after serial number MSLC61642 shipped

after 12/2003 use white LED lighting)

- STEREO LINK SWITCH

Several units can be linked for Surround (custom order )

- Maximum gain: 35dB

- Max. output: +30dBu (26Vrms) 26dB Headroom

- <0.1% THD @ 1kHz Noise floor: -85dB typical

- Power Consumption (120/240VAC): 80 watts

- Unit is factory set for 100V, 120V or 220-240VAC operation for original destination country’s

mains voltage.

- Operating Mains Voltage changeable with power transformer changeover switch and fuse value

change.

- Mains Voltage Frequency: 50~ 60Hz

- Dimensions: 19” x 3 1/2” x 10” (chassis occupies 2U). Power transformer protrudes 3.5” out the

back of the chassis.

- Shipping Weight: 23 lbs.

14
