- Determine the number of ignition pulses per crank rotation. Refer to Table 2 or 3 for
guidance.
-
Press the ‘Channel’ button until it shows channel 1.
- Press the ‘Function’ button until it shows 1 or 2. Use 1 if your engine’s redline is below
10000 RPM. Otherwise use 2.
- Press the ‘Calibrate’ button until the selected Cyl. Number appears
Table 2: Cylinder number and RPM calibrate number 4 Cyl engine
Number
of
Cylinders 4-Stroke
pulses/Crank
-Rotation Calibrate
Number Comment
1 1/2 1 Use also when using inductive clamp
on spark wire or power wire of COP
system of 1 cylinder only for all cylinder
numbers
2 1 2 Use also when using inductive clamp
on spark wire or power wire of Waste
spark coil of 1 cylinder only.
Waste spark system:
1 coil for every 2 cylinders.
3 1-1/2 3
4 2
4
5 2-1/2 5
6 3
6
8 4 8
10 10 A
12 12 C
Table 3:: Cylinder number and RPM calibrate number 2 Cycle and Rotary Engine
Number
of
Cylinders 2-Stroke
pulses/Crank
-Rotation Calibrate
Number Comment
1 1 2 Use also when using inductive clamp
on spark wire or power wire of COP
system of 1 cylinder only for all cylinder
numbers
Also use for rotary engine.
2 2 4 Use also when using inductive clamp
on spark wire or power wire of Waste
spark coil of 1 cylinder only.
Waste spark system:
1 coil for every 2 cylinders.
3 3 6
4 4 8
5 5 A
6 6 C
7.4 Using the DL-32 with the Inductive Clamp
