8
2.4.1 Calibration Schedule
Normally aspirated (daily driver)
- Calibrate before installation of new sensor
- Calibrate new sensor again after 3 month of use
- Thereafter calibrate once a year or every 20,000 miles, whichever comes
first
Turbo Application, daily driver (tuned rich)
- Calibrate before installation of new sensor
- Calibrate new sensor again after 3 month of use
- Thereafter calibrate twice a year or every 10,000 miles, whichever comes
first
Race Application
- Calibrate before first installation of new sensor
- Calibrate once per race weekend
2.5 Changing the MTX-L’s gauge face and/or bezel
1. Lay the MTX-L face down and remove the three #2 phillips screws
from the outside rim of the back plate.
2. Carefully lift out the bezel from the gauge cup.
3. Configure the gauge as desired by changing the gauge face and or
bezel.
*Be sure to remove protective film from the gauge face. This can be
done easily with a piece of scotch tape.
4. Make sure every piece is positioned correctly using the locating tab
and reassemble the gauge.
5. Reinstall the 3 #2 phillips screws.
3 Download the Logworks 3 software package
1. Open your web browser and go to:
http://www.innovatemotorsports.com/support.php
2. The LogWorks 3 software download will be the very first thing on the
page, click the link to download the software.
