17
3. Turn the secure dial clockwise till the lock dial clicks. The small red tab should then be pointed
towards the bottom of the housing (image #13).
4. Gently try pulling the back door away from the front door. If the housing is properly closed, it
should be impossible to open the back door.
5. Visually inspect the O-ring for proper closure. Make sure it isn’t twisted or out of the groove and
that no foreign matter has been caught in the seal, such as secure lines or hairlines.
6. Turn on the camera and check that the extended camera lens does not catch or bend the black
rubber seat on the inside of the lens port. It is vital that the lens does not disturb this rubber
seat.
7. Test housing control buttons to make sure that the camera was properly installed inside the
housing and that nothing interferes with normal operation of the camera. It is recommended to
take a few images once the camera has been installed inside the housing and prior to the dive in
order to ensure proper operation.
8. If making use of the internal camera flash, install the removable flash diffuser on the housing
and attach the flash diffuser quick release secure string in order to avoid losing it underwater.
Please refer to the section “Using the Built-in Camera Flash” for further information.
9. Prior to diving with the housing, submerge it in a shallow tub of water or rinse tank. Carefully look at
the housing to make sure no bubbles are escaping from it and that no water is entering.
REMOVING THE CAMERA FROM THE HOUSING
1. After use and prior to opening the housing, make sure both your hands and the housing are
clean and dry. It is recommended to have a clean, dry and soft towel handy in order to dry your
hands and the water drops on the housing.
Image #12 Image #13
