APRON ASSEMBLY
PARTS LIST
APRON ASSEMBLY
MODEL I-160
KEY NO. PART NO. DESCRIPTION
1. A16025A Apron Model I-160, s/n 17332 to 17581
A16025B Apron Model I-160, s/n 17642 to 17697
A16025C Apron Model I-160, s/n 17698 and up
2. AFN-00009 Self Lock Nut, 1-1/4”NF
AFN-00018 Self Lock Nut, 1-1/2” NF
3. A6010 Shoulder Pin, 1-5/8” x 1-1/4”, up to s/n. 17130
A17506 Shoulder Pin, 2-1/4” x 1-1/4”, s/n 17332 to 17581
A17506A Shoulder Pin, 2-1/4” x 1-1/2”, s/n 17642 to 17697
----- Bolt, 1-1/2”NF x 6” Lg., for s/n 17698 and above
4. 14505 Grease Fitting, 1/8” NPT
5. A10155 Bushing, 1-1/2” OD x 1” ID x 1” Lg.
6. A16027 Bushing, 2” OD x 1-1/2” ID x 2” Lg. for s/n 17698 and above
9
