PARTS LIST
GOOSENECK FRAME ASSEMBLY
MODEL I-160
KEY NO. PART NO. DESCRIPTION
1. A14001B Gooseneck Frame for serial number 17815 and up
2. ----- Bolt, 1/2” NC x 3-1/2” Lg.
3. ----- Grease Zerk - Straight
4. A10152A Pin, Frame Attach
5. ----- Hair Pin
6. A10153 Pin, Transport Lock
7. ----- Bolt, 7/8”NF x 5” Lg. Grade 8
8. ----- Nut, 7/8”NF
9. ----- Lockwasher 7/8”
10. A14002 Cast Socket Half - Rear
11. A14003 Cast Socket Half - Front w/Zerk Hole
12. A2206 Grease Zerk - Long Shank
13. A14039 Bushing, 2-3/8” OD x 2” ID x 2” Long
GOOSENECK FRAME ASSEMBLY
8
