Ashland I-140 - Manual (Page 6)

PARTS LIST
GOOSENECK FRAME ASSEMBLY
MODEL I-140
KEY NO. PART NO. DESCRIPTION
1. A14001B Gooseneck Frame for serial number 17815 and up
2. AFB-00054 Bolt, 1/2” NC x 3-1/2” Lg.
3. 14505 Grease Zerk - Straight
4. A10152A Pin, Frame Attachment, 2” OD x 8-1/16” Long
5. ----- Hair Pin
6. A10153 Pin, Transport Lock
7. ----- Bolt, 7/8”NF x 5” Lg. Grade 8
8. 7597 Nut, 7/8”NF
9. 8125 Lockwasher 3/4”
10. A14002 Cast Socket Half - Rear
11. A14003 Cast Socket Half - Front w/Zerk Hole
12. A2206 Grease Zerk - Long Shank
13. A14039 Bushing, 2-3/8” OD x 2” Long
I-140 GOOSENECK FRAME ASSEMBLY
6
