HOW TO ORDER PARTS:

IMPORTANT

Parts must be ordered through your local authorized ASHLAND dealer.

Be sure to state MODEL and SERIAL NUMBER of your machine, PART NUMBER, DESCRIPTION

and QUANTITY needed.
Unless this is done, we cannot provide prompt service or assure shipment of the correct parts.

Page 3.

Operators and Maintenance Instructions

Page 4.

Safety Guidelines

Page 5.

Illustration - Assembly

Page 6.

Illustration and Parts List - Gooseneck Frame Assembly

Page 7.

Illustration and Parts List - Apron Assembly

Page 8.

Illustration - Bowl and Frame Assembly

Page 9.

Parts List - Bowl and Frame Assembly

Page 10.

Illustration and Parts List - Push Off Gate Assembly

Page 11.

Illustration and Parts List - Pole and Axle Assembly

Page 12.

Illustration and Parts List - Front Wheel and Hub Assembly

Page 13.

Illustration and Parts List - Rear Wheel, Spindle and Hub Assembly

Page 14.

Illustration and Parts List - Apron Cylinder, 4” x 13”, Right

Page 15.

Illustration and Parts List - Apron Cylinder, 4” x 13”, Left

Page 16.

Illustration and Parts List - Hydraulic Lift Cylinder, 5” x 20”

Page 17.

Illustration - Pushoff Cylinder, 4-1/2” x 60”

Page 18.

Parts List - Pushoff Cylinder, 4-1/2” x 60”

Page 19.

Illustration - Hydraulic Circuit

Page 20.

Parts List - Hydraulic Circuit

Page 21-25. Service Manual Appendix

Page 26-27. Troubleshooting

Page 28.

Warranty Statement

2

INDEX

Ashland Industries weldable replacement parts are availabe to rebuild, modify or

update your scraper to current factory specifications.

Model I-140 Scraper
