ASHLAND SCRAPERS
Hydraulic Hoses (I-180TS2)
KEY PART DESCRIPTION
1 A125297 Barrel End, R. Lift Cyld. to Top Front Tube - 23.5"
2 A125298 Rod End, R. Lift Cyld. To Top Rear Tube - 31"
3 A125299 L & R Front Top Tube to Rear Top Tube - 48"
4 A125300 Rod End, R. Apron Cyld. to Rear Inner Top Tube - 38"
5 A125301 Barrel End, R. Apron Cyld. to "T" at Rear Outside Top Tube -34"
6 A125302 L & R Rear Outside Bottom to Front Outside Bottom Tube - 43"
7 A125303 Rear Outside Top Tube @ "T" to Front Inside Bottom Tube - 52"
8 A125304 Rod End .. Apron Cyld, to "F" Port on Valve-38.5"
9 A125305 Barrel End. L. Apron Cyld. To "E" Port on Valve - 31"
10 A125306 "A" Port on Valve to Front Bottom Inside Tube - 66"
11 A125307 Barrel End R. Pushoff Cyld. to Top R. Side of "T" - 104"
12 A125308 Barrel End L. Pushoff Cyld. to Center Top "T" - 77.5"
13 A125309 Rod End L & R Pushoff Cyld. to Bottom "T" - 24.5"
14 A125310 Rear Inside Tube to Top Rear Valve Connector-22"
15 A125311 Rear Outside Tube to Rear Valve Connector-19"
16 A125312 Front Top Inside Tube to Bulkhead - 31"
17 A125313 Front Top Outside Tube to Bulkhead - 32.5"
18 A125314 Front Bottom Inside Tube to Bulkhead - 29.5"
19 A125315 Front Bottom Inside Tube to Bulkhead - 30.5"
20 A125181 3/4 X 85" Connecting Hose Bulkhead to Tractor
