ASHLAND SCRAPERS
Wheel Assembly (900-950)
KEY PART DESCRIPTION SN 950 REMARKS
1 A9060 Spindle, Rear with flange base plate
2 A8020 Grease Seal (CR 35062)
3 A9061 Bearing Cone, inner
4 A8022 Bearing Cup, inner
5 A125319 Hub 22410-XXXXX
A8023 Hub XXXXX-22409 Obsolete
6 A125320 Stud: Wheel 5/8" 22410-XXXXX Pressed-in
6 A4519 Wheel Bolt, 9/16" NF XXXXX-22409
7 A8024 Bearing Cup, outer
8 A8025 Bearing Cone, outer
9 A6022A Front Wheel 16.1 X 11" DC
9 A6023 Rear Wheel 24" x 15"
10 A8026 Hub Cap
11 AFP-00002 Cotter Pin, 3/16" x 1-3/4"
12 AFN-00005 Spindle Nut
13 A8027 Spindle washer, special
14 AFP-00001 Bolt, 1" NC x 6-1/2" long
15 AFN-00012 Nut, 1" NC
16 AFW-00001 Flat Washer, 1"
17 A125321 Nut: Wheel 5/8" 22410-XXXXX
