Acer al200 - Manual (Page 17)

AL2002W
E-15
SPECIFICATION
LCD Display
Display Type
20" TFT LCD
Display Area (W x H) 433.4 x 270.9 mm
Contrast Ratio 800:1 (Typ.)
Viewing Angle 160 o H 160 o V (CR=10)
Power Input
Voltage
100-240Vac
Frequency 50-60Hz
Current Rating 1.5A
Operational Features
Display Colors
16.7M
Resolution WSXGA (1680 x 1050) at 60 Hz maximum.
Brightness 300 cd/m 2 (Typ.)
Response Time 5 ms (Typ.)
Interface Analog RGB, Digital(Only Dual-Input Model)
Input Connector 15-pin D-sub, DVI-D Cable(Only Dual-Input Model)
Users Controls
Front Panel Controls
Power On/Off, MENU, Select DOWN( ),Select
DOWN( ) to switch Analog and Digital Value(+/-
)(Only Dual-Input Model), +/AUTO,-.
OSD Controls
(Note) Brightness, Contrast, Auto Contrast, Color
Temperature, Horizontal Size, Fine, Left/Right,
Down/Up, Auto-Adjust, Language, Factory Reset,
OSD Time Out, OSD Left/Right, OSD Down/Up,
Information
Note : for DVI mode, Auto Contrast, Horizontal
size,Fine, Left/Right, Down/Up, Auto Adjust will
bedisabled.
