Specifications
75
DEQ230D
Analog I/O (switchable)
Input connectors:
2 balanced 1/4” TRS jacks
Output Connectors:
2 balanced 1/4” TRS jacks
Switch set to +4:
Nominal input level:
+4dBu (-15dBFS)
Maximum input level:
+19dBu (6.9 Vrms)
Nominal Output Level:
+4dBu (-15dBFS)
Maximum Output Level:
+19dBu (6.9 Vrms)
Switch set to –10:
Nominal input level:
-10dBV (-16dBFS)
Maximum input level:
+6dBV (2.0 Vrms)
Nominal Output Level:
-10dBV (-16dBFS)
Maximum Output Level:
+6dBV (2.0 Vrms)
Input impedance:
10kΩ
Output Impedance:
220Ω
DEQ230
Input connectors:
2 balanced 1/4” TRS jacks
Output Connectors:
2 impedance-balanced
1/4” TRS jacks
Nominal input level:
-10dBV (-18dBFS)
Maximum input level:
+8dBV (2.5 Vrms)
Nominal Output Level:
-10dBV (-18dBFS)
Maximum Output Level:
+8dBV (2.5 Vrms)
Input impedance:
10kΩ
Output Impedance:
220Ω
Audio Performance
Signal To Noise Ratio:
>96 dB A-Weighted, Analog In
to Analog Out
THD+N:
<0.005%, Analog In to Analog
Out
Frequency Response:
22-22kHz ± 0.50dB, Analog In
to Analog Out
Power Consumption:
15 Watts Max (100-240 VAC /
50-60
Hz)
Mechanical
Size:
1.75" H x 19.0" W x 5" D
Rack Spaces:
1 Space
Weight:
3.0 lbs. (1.4 kg)
All measurements done over
a 22 Hz - 22 kHz range with 1
kHz sine wave at -1dBFS
input. Impedances are
measured at 1 kHz.
