Hold Down, Conveyor Chain.....21
Hold Down, Conveyor Chain, Long.....25
Hold Down, Conveyor Chain, Short.....25
Holder, Plug Storage.....51
Hook, Cover (Rubber).....22
Hose, Brake, 3/8 x 122 in......41
Hose, Brake, 3/8 x 139 in. - G6070 &
G6070P.....41
Hose, Grease, 3/16 in. x 32 in......21, 25
Hose, Grease, 3/16 in. x 40 in......21, 25
Hose, Grease, 3/16 in. x 47 in......21, 25
Hose, Hydraulic, 1/4 in. x 26.5 in. 6 x 6
FJIC.....39
Hose, Hydraulic, 3/8 in. x 42 in. 6 FJIC 45° x
6 FJIC.....39
Hose, Hydraulic, 3/8 in. x 72 in. 6 FJIC 90° x
6 FJIC.....39
Hose, Hydraulic, 3/8 NPT x 22 in. 2WB -
1.000.....67
Hose, Hydraulic, 3/8 x 144 in......81
Hose, Hydraulic, 3/8 x 150 in......81
Hose, Hydraulic, 3/8 x 152 in. (Cable Rewind
Motor Return to Filter).....68
Hose, Hydraulic, 3/8 x 155 in. (Valve Pressure
to Cable Rewind Motor).....68
Hose, Hydraulic, 3/8 x 24 in......81
Hose, Hydraulic, 5/8 x 19 in. (Valve Return to
Filter).....68
Hose, Hydraulic, 5/8 x 25 in. (Main Tank
Pressure to Valve).....68
Hose, Hydraulic, 5/8 x 52 in. (Valve Pressure
to Conveyor Motor).....68
Hose, Hydraulic, 5/8 x 57 in. (Conveyor Motor
Return to Filter).....68
Hose, Return, 3/4 x 34 in. (Upper Auxiliary
Tank to Main Tank).....68
Hose, Return, 3/4 x 43 in. (Filter to Lower
Auxiliary Tank).....68
Housing, R700 TAP Improved.....55
Housing, R700 THRU Improved.....55
Hsg, Main Mach R70C.....57
Hub Assembly With Cups & Studs.....13
I
I.Cone, Shield Cone, #8-9 Inner (Not Serviced
Separately).....63
Inboard Yoke, S4.....65
Inboard Yoke, S5.....65
Individual Cartridge (Included with Item 1)..81
Inner Profile, S4LGA.....65
Inoculant, Granular, 50 lb Bucket (Treats 100
Ton).....75
Inoculant, Liquid 250 Ton Foil Pouch For Inject.
Sprayer.....75
Inoculant, Liquid 50 Ton Foil Pouch.....75
Instruction Booklet (Not Serviced).....63
J
Jack Base, Hydraulic Lift.....81
Jack, Manual, 15 in. Square Mount.....7
K
Key, 5/8 x 5/8 x 1.845.....55, 57
Key, 5/8 x 5/8 x 2-3/4 in......17
Key, Shaft (Hydraulic Motor).....26, 31, 67
Key, Sq, 3/4 x 3/4 x 4 in. - (G6060 S/N
42.05167 & Before) & PB6000 Only.....17
Key, Sq, 7/8 x 7/8 x 4 in. - G6070 & (G6060
S/N 42.05168 & After).....17
Key, Square, 1/4 in. x 1-3/4 in......21, 26
Key, Square, 1/4 in. x 2 in......21, 26
Key, Square, 1/4 x 1/4 x 2 in......71
Key, Square, 3/8 in. x 3 in. Undersize.....7
Key, Square, 3/8 x 3/8 x 2 in......71
Kit, Ball Collar, 1-3/8 in. #8.....63
Kit, Bungee Cord (Consists Of Items 11a &
11b).....11
Kit, Hydraulic Conveyor Lift (Consists Of Items
1 & 2 thru 20).....39
Kit, PTO Transport (Includes Items 1 thru
10).....59
Kit, RT Ball Collar S5/S9, 1-3/4 in......63
Knob.....67
Koster Moisture Tester - Not Shown.....75
L
Latch.....21, 26
Lens, Amber (Command).....51
Lens, Amber (Wesbar).....51
Lens, Red (Command).....51
Lens, Red (Wesbar).....51
Light Stand Weldment.....51
Light Tube Weldment, Left Side.....51
Light Tube Weldment, Right Side.....51
Light, Dual Lamp, Amber/Red, Left Side.....51
Light, Dual Lamp, Amber/Red, Right Side...51
Link, #120-2 Connector UST.....17
Link, #50 Connector UST.....71
Link, #CA550 Offset.....21, 26
Link, CA550 Connector.....31
Link, CA550 Offset.....31
Link, Offset, #120-2.....17
Liquid Inoculant Applicator, 15 Gallon Sprayer
- Not Shown.....75
Liquid Inoculant Applicator, 27 Gallon Sprayer
- Not Shown.....75
Liquid Inoculant Applicator, 55 Gallon Sprayer
- Not Shown.....75
Lock Assembly.....65
Lock Collar Kit.....65
Lock, PTO Cradle.....59, 61
Lube/Shc 75W90 Synth.....57
Lug Nut, 9/16-18.....13
M
Machine Bushing, 1-1/4 in......29
Master Seal Zip Tool.....75
Master Seal, 14.5 ft Lengths 4/Box For 8 & 9
ft Bags.....75
Master Seal, 17 ft Lengths 4/Box For 10 ft
Bags.....75
Master Seal, 20 ft Lengths 4/Box For 11 & 12
ft Bags.....75
Master Seal, 250 Ft Roll.....75
Master Seal, 9.5 ft Lengths 4/Box.....75
Motor, Electric, w/Brackets & Harness.....79
Motor, Hydraulic, 101-1019-009, 5.9 cu. in.
(PB6000 Only).....31
Motor, Hydraulic, 101-1751-009, 7.3 cu. in.
(G6060 & G6070 Only).....31
Motor, Hydraulic, Charlyn 101-1272.....68
Motor, Hydraulic, Conveyor.....26, 67
Mount, (Weld On), Jack, Female Square
Tubing.....7
Mount, Bracket, Drive Motor.....25
Mount, Hydraulic Motor.....21
Mount, Hydraulic Motor (G6060 & PB6000
Only).....31
Mount, Hydraulic Motor, 101 Series.....67
N
Nut, Hex Center Lock, 7/16-14.....22
Nut, Hex Flange Lock, 1/2-13 Nylock.....21
Nut, Hex Flange Lock, 1/4-20 Nylock Yellow
Zinc.....21, 26
Nut, Hex Flange Lock, 3/8-16 Nylock Yellow
Zinc.....21, 26
Nut, Hex Flange Lock, 3/8-16 Yellow Zinc -
G6070 & G6070P.....41
Nut, Hex Lock Flange, 3/8-16 Yellow Zinc
Nylock.....83
Nut, Hex Lock, 1/2-13.....32
Nut, Hex Lock, 1/2-13 Nylock.....7, 9, 29, 51
Nut, Hex Lock, 1/2-13 Nylock Stainless
Steel.....26
Nut, Hex Lock, 1/4-20.....32
Nut, Hex Lock, 1/4-20 Nylock.....51, 81
Nut, Hex Lock, 1/4-20 Nylock Stainless
Steel.....22, 41, 71
Nut, Hex Lock, 1/4-20 Nylock Stainless Steel
- G6060 & PB6000.....19
Nut, Hex Lock, 1/4-20 Nylock Stainless Steel
- G6070 & G6070P.....19
Nut, Hex Lock, 1/4-20 Whizlock.....68
Nut, Hex Lock, 3/4-10 Nylock.....7, 9, 17
Nut, Hex Lock, 3/8-16.....32
Nut, Hex Lock, 3/8-16 Nylock....11, 45, 51, 81
Nut, Hex Lock, 3/8-16 Nylock Stainless
Steel.....11
Nut, Hex Lock, 5/16-18 Nylock.....29
Nut, Hex Lock, 5/8-11 Nylock.....7, 9, 11, 21,
26, 35, 41, 45, 47
Nut, Hex Lock, M14-2 CLS 10 Nylock.....9
Nut, Hex Lock, Nylon Flange, 5/16-18 Blk
Zinc.....59, 61
Nut, Hex Nylon Flange Lock, 1/2-13.....67, 71
Nut, Hex Nylon Flange Lock, 1/2-13 - G6070
& G6070P.....41
Nut, Hex Nylon Flange Lock, 3/8-16 Yellow
Zinc.....35, 67, 71
Nut, Hex Top Lock, 5/8-11.....77
Nut, Hex Whiz Lock, 1/4-20.....39
Nut, Hex Whiz Lock, 3/8-16.....37, 59
Nut, Hex, 1/2-13.....17, 22, 25, 31
Nut, Hex, 3/4-10.....77
Nut, Jam 1/2-13.....22
Nut, Slotted Lock, NO6 Zinc Plated.....13
O
O-Ring, Rubber, Gandy.....79
O-Ring, SAE -8 (.64 I.D.).....81
O.Cone, Shield Cone, #8-9 Outer Std......63
Oil Seal, 2.25 I.D......13
Orifice, -6 Two Way, .049 in. Dia......39
Orifice, -8 ORB One Way, .059 in......81
G6070/G6070P - 91 - 42.0901805A Issue Date: 10/11
Part Description Index
(continued)
